8/6/8mm Twin Wire Fence

8/6/8mm Twin Wire Fence

Products Description:

The Double Wire Fence, also known as twin wire fence, 2D panel fence, or double wire mesh fence, is a heavy-duty welded fence system designed for long-term perimeter protection. Each mesh panel is composed of one vertical wire welded between two horizontal wires, offering outstanding rigidity and impact resistance. Compared with ordinary welded mesh fences, the double wire fence provides higher strength, improved anti-damage capability, and a clean, modern appearance suitable for both residential and industrial use.

Our Double Wire Fence is manufactured from high-quality Q195/Q235 low-carbon steel wire, processed with precise welding technology to ensure firm solder joints and flat panel surfaces.
The fence is commonly made with 6/5/6 mm or 8/6/8 mm wire combinations — meaning the vertical wire is 5 mm or 6 mm, and the two horizontal wires are 6 mm or 8 mm respectively. This configuration significantly increases structural strength and resistance to bending or cutting.
Double Wire Fences are compatible with double-peach posts,I-type posts ,and Y-type posts (which can be equipped with barbed wire).

• Panel Height: 1500mm,1800mm,2000mm,2200mm,2400mm,2800mm
• Panel Width:2000 mm, 2200mm,2500 mm, 3000 mm
• Wire Diameter: 6/5/6 mm, 8/6/8 mm
• Mesh Opening: 50 x100 mm, 50 x 150 mm, 50 x 200 mm, mm, 55 x 200 mm, 75 x 100mm,75x150mm,100x200mm
• Clamp:metal clamp
• Post
  • Round post (48 0D x1.5/2.0 mm, 60 0D x 1.5/2.0 mm);
  • Square post (50 x50 x1.5/2.0 mm,60 x60 x1.5/2.0 mm, 80 x80 x 1.5/2.0 mm);
  • Rectangular post (40 x60 x1.5/2.0 mm,40 x80 x1.5/2.0 mm, 60 x 80 x 1.5/2.0mm,80x100 x1.5/2.0 mm)
  • Doubel post (55x100mm/1.5mm)
  • Post Cap: metal cap/anti-UV plastic cap

Features

• High Strength & Stability: The twin horizontal wire design doubles the rigidity and effectively resists deformation and external impact.
• Corrosion & Weather Resistance: Hot-dip galvanizing and polyester powder coating offer long-lasting rust prevention, with a service life of over 10–15 years.
• Easy Installation: Modular structure allows quick installation on both flat and sloped terrain.
• Sizes & Colors: Available in common RAL colors such as Black 9005, Green 6005, and Grey 7016, or fully customized shades.
• Attractive Appearance: The symmetrical twin wire design gives a modern and clean visual effect ideal for public areas.
• Low Maintenance: Smooth surface coating minimizes dust accumulation and is easy to clean.

Installation Method and Accessories of double wire fence

Different installation methods can be chosen for the double wire fence, and with different accessories.

Packing and Delivery
